Stretch out in comfort and style and show off a healthy dose of street attitude, with 16” Polished Ape Hanger Handlebars. They add to the custom style of your bike and provide a comfortable reach to the grips and controls.
Provide your passenger with a secure, comfortable backrest in just seconds by adding a Quick Release Passenger Sissy Bar and Genuine Leather Passenger Backrest Pad (sold separately). Quick Release technology lets you install or remove the entire backrest in seconds without tools.
A Thunder Stroke® Stage 1 Exhaust delivers a rich, deep, and powerful exhaust note that truly represents the Thunder Stroke® V-Twin’s outstanding performance. For ultimate custom style, add a set of Fish Tail Exhaust Tips.
ENGINE
Engine Type Thunder Stroke® 111
Displacement111 cu in (1811 cc)
Bore x Stroke3.976 in x 4.449 in (101 mm x 113 mm)
Compression Ratio9.5:1
Electronic Fuel Injection System Closed loop fuel injection / 54 mm bore
DRIVETRAIN
Primary Drive Gear Drive Wet Clutch
Drive/Driven Clutch Wet, Multi-Plate
Final Drive 2.2: 1
PERFORMANCE
Peak Torque119.2 ft-lbs (161.6 Nm)
Peak Torque RPM3000 rpm
GEAR RATIO (OVERALL)
1st9.403 : 1
2nd6.411 : 1
3rd4.763 : 1
4th3.796 : 1
5th3.243 : 1
6th2.789 : 1
SUSPENSION
Suspension: Front - Type/TravelTelescopic Fork / 4.7 in (119 mm)
Front Fork Tube Diameter46 mm
Suspension: Rear - Type/TravelSingle Shock / 3.7 in (94 mm)
CHASSIS
Brakes/FrontDual / 300mm Floating Rotor / 4 Piston Caliper
Brakes/RearSingle / 300mm Floating Rotor / 2 Piston Caliper
Wheels/Front40 Spoke 16 in x 3.5 in
Wheels/Rear40 Spoke 16 in x 5 in
Tires/FrontDunlop® American Elite 130/90B16 67H
Tires/RearDunlop® American Elite 180/65B16 81H
ExhaustSplit dual exhaust w/ cross-over
DIMENSIONS
Wheelbase68.1 in (1730 mm)
Seat Height26.0 in (660 mm)
Ground Clearance5.5 in (140 mm)
Overall Height58.7 in (1490 mm)
Overall Length103.7 in (2634 mm)
Overall Width39.4 in (1000 mm)
Rake29°
Trail6.1 in (155.0 mm)
Fuel Capacity5.5 gallons (20.8 liters)
GVWR1260 lbs (573 kg)
Weight (Empty Tank / Full of Fuel)824 lbs / 856 lbs (374 kg /388 kg)
FEATURES
Color / GraphicsThunder Black
STANDARD
Standard EquipmentABS; Cast Aluminum Frame with Integrated Air-Box; Cruise Control; Highway Bar; Indian® Script Tank Badge; Keyless Start; Light Bar; Desert Tan Genuine Leather Seats; Quick Release Windshield; Quick Release Vintage Leather Saddle Bags; Vintage Fender Badge
ELECTRICAL
GaugesTank mounted electronic speedometer with odometer; dual tripmeters; digital tachometer; ambient air temperature; fuel range; average fuel economy; battery voltage; gear position display; real-time clock; vehicle trouble code readout; heated grip level (if heated grips installed); low engine oil pressure; and 9 LED telltale indicators: High Beam, Chassis Fault, Turn signals (separate), ABS, Neutral, TPMS, Check Engine, Sidestand; Tank mounted electronic fuel gauge with low fuel LED indicator
